(2) Description of hardware setting
AP2G3-337~375 AP4G3-337~3110
AP2G3-3110~3220 AP4G3-3150~3220
(3) RS485 connector
9
NO 8 7 6 5 4 3 2 1
Color Black Red Orange Yellow Green Blue Purple Brown
Symbol GND VCC GND A RFA0 B VCC
Connect to F306 or RS485
This connector is for RS485. Set CD13 for selection.
※
8765 4321
GND 10V FA1 FA2 MET MA MB MC A B C 24V FWD REV CF1 FT2CF2 FT1 ARRRST COMCOM
RS485
SW1
431 2
S1
65
GND 10V FA1 FA2 MET MA MB MC A B C 24V FWD REV CF1 FT2CF2 FT1 ARRRST COM COM
RS485
S1
SW1
431 2 65
