4. INSTALLATION
Inadequate environment around installation site and installation
surface can result in damage to the inverter.
Before operating the APxG3 series inverter, please check the following
points :
(1) Avoid high temperature, high humidity, easy-to-dew ambient envi-
ronment. Don’t expose to dust or dirt, corrosive gas, and coolant
mist, and direct sunlight. Place the unit in a well-ventilated room.
(2) Avoid a place subjected to substantial vibration.
(3) When installing the unit within the cabinet. Please pay attention to
ventilation and limit the ambient temperature in between -10
℃ ~
45
℃ . (14℉ ~ 113℉ ).
(4) Use a nonflammable material, such a steel sheet on the wall for
installation. (The rear side will generate heat)
(5) Install the unit always vertically with a marginal spacing around.
6
AIR FLOW
15 cm
15 cm
5 cm
10 cm
10 cm
