1. RECEIVING
Befor installation and wiring, check to see :
(1) No damage is found on each product after shipping.
(2) The product is as ordered (check the nameplate, voltage and fre-
quency).
(3) A set of inverter unit and instruction manual is contained in the
package.
For any irregularity, contact the sales shop where you purchased
immediately.
(4) Description of name plate
MODEL : AP 4 G3 - 3 37
Max Applicable motor(4 pole)
37 : 3.7KW 55 : 5.5KW 75 : 7.5KW
110 : 11KW 150 : 15KW 185 : 18.5KW
220 : 22KW
3 : 3
AP series
Voltage class :
2 : 200/240V
4 : 380/440V
IPM AC drive
