19
DISPLAY
CODE
FUNCTION DEFAULT VALUE
CD20 DC braking power 10
CD21 Torque boost 0.0%
CD22 Second speed setting 20.00HZ
CD23 Third speed setting 30.00HZ
CD24 Fourth speed setting 40.00HZ
CD25 Acceleration time 2 10.0Sec
CD26 Deceleration time 2 10.0Sec
CD27 Carrier frequency
15.0K
10.0K
CD28 Output voltage gain 100.0%
CD29 Frequency jump 1 0.00
CD30 Frequency jump 2 0.00
CD31 Freuqency jump 3 0.00
CD32 Jump range 0.50HZ
CD33 Frequency reference bias 0.00
CD34 Frequency reference bias direction 0
CD35 Frequency gain 100.0 %
CD36 The latest errors record NONE
CD37 Errors record 1 NONE
CD38 Errors record 2 NONE
CD39 Errors record 3 NONE
CD40 Clear errors record 0
CD41 HZ / RPM / AMP / DC bus Display 0
CD42 FT1 Multi-Function Terminal 1 0
CD43 FT2 Multi-Function Terminal 2 0
