Adleepower AP4G3 - Write parameter setting into AC drive

61
Computer write CD00 content (60.00HZ) to inverter address=52
1. RTU
Computer command message
AC drive response message
D1
34H
D2
06H
D3
00H
D4
00H
D5
17H
D6
70H
D7
CRCL
D8
CRCH
D1
34H
D2
06H
D3
00H
D4
00H
D5
17H
D6
70H
D7
CRCL
D8
CRCH
(2) 06H : Write parameter setting into AC drive
Computer command message
D1 : Communication address
D2 : Function code
D3 : Parameter number (H)
D4 : Parameter number (L)
D5 : Content of data (H)
D6 : Content of data (L)
D7 : CRCL
D8 : CRCH
(00~FFh)
(06h)
(00h)
(0~4Eh)
(0~FFh)
(0~FFh)
(0~FFh)
(0~FFh)
AC drive response message
D1 : Communication address
D2 : Function code
D3 : Parameter number (H)
D4 : Parameter number (L)
D5 : Content of data (H)
D6 : Content of data (L)
D7 : CRCL
D8 : CRCH
(01~FFh)
(06h)
(00h)
(0~4Eh)
(0~FFh)
(0~FFh)
(0~FFh)
(0~FFh)
