69
Computer command message AC drive response message
D3
Number of parameter '0'
Number of parameter '0'
30
D3
Number of parameter '0'
Number of parameter '0'
30
30 30
D4
Number of parameter '0'
Number of parameter '0'
30
D4
Number of parameter '0'
Number of parameter '0'
30
30 30
D5
CD79 content '1'
CD79 content '7'
31
D5
CD79 content '1'
CD79 content '7'
31
37 37
D6
CD79 content '7'
CD79 content '0'
37
D6
CD79 content '7'
CD79 content '0'
37
30 30
D7 LRC HI LRC HI D7 LRC HI LRC HI
D8 LRC LO LRC LO D8 LRC LO LRC LO
END HI 0D END HI 0D
END LO 0A END LO 0A
Step 2. Write address 100 (64H)=1
Computer command message AC drive response message
STX 3A STX 3A
D1
Address '3'
Address '4'
33
D1
Address '3'
Address '4'
33
34 34
D2
Function '0'
Function '6'
30
D2
Function '0'
Function '6'
30
36 36
D3
Content of data '0'
Content of data '0'
30
D3
Content of data '0'
Content of data '0'
30
30 30
D4
Content of data '6'
Content of data '4'
36
D4
Content of data '6'
Content of data '4'
36
34 34
D5
CD31 content '0'
CD31 content '0'
30
D5
CD31 content '0'
CD31 content '0'
30
30 30
