5. DESCRIPTION OF TERMINALS
(1) Main circuit connection diagram
MS1-104, MS2-102~122
MS2-307~322, MS4-307~322
MS2-137
9
L1 L2 L3 U V W
PRP
MOTOR
POWER
GROUND
External braking resistor
Refer to the appendix A
SOURCE
180 80W
Ω
L1 L2 U V W PRP
MOTOR
GROUND
External braking resistor
Refer to the appendix A
60 80W
SOURCE
POWER
Ω
L1 L2 V W
MOTOR
GROUND
P PR
POWER
SOURCE
U
180 80W
Refer to the appendix A
External braking resistor
Ω
