1. RECEIVING
This MS series AC drive has gone through rigorous quality control tests
at the factory before shipment. After receiving the AC drive, please check
for the following :
(1) No damage is found on each product after shipping.
(2) The product is as ordered (check the nameplate, voltage and fre-
quency).
(3) A set of inverter unit and instruction manual is contained in the
package.
For any irregularity, contact the sales shop where you purchased
immediately.
(4) Description of name plate
1
MODEL : MS 2 - 115
Max Applicable motor(4 pole)
Single Phase :
102 : 0.2KW 104 : 0.4KW 107 : 0.75KW
115 : 1.5KW 122 : 2.2KW 137 : 3.7KW
3 Phase :
307 : 0.75KW 315 : 1.5KW 322 : 2.2KW
337 : 3.7KW
MS series
Voltage class :
1 : 110V
2 : 220V
4 : 380/440V
