ADT Pulse MDC835 - Reattaching the Camera Bubble

Chapter 4 Ceiling Mounting
17
CAUTION
Make sure that the LVDS cable does not cover up
or become caught on the antenna.
Figure 8: LVDS Cable
7. Attach the bubble to the camera, and then secure it using the three
screws.
NOTE
Use the alignment marks to properly align the
camera and bubble while attaching them together.
Figure 9: Reattaching the Bubble
CAUTION
Make sure to tighten up the three screws in order
to prevent water ingress.
