ADTECH9 Series CNC Programming Manual

Compensation number change in compensation mode

In compensation mode, the compensation No. shouldn’t be changed in principle. To change, the motion is

shown in the figure below:

G41 G01………………………………….Dr1;

α=0,1,2,3

N101 G00 α Xx1 Yy1;

N102 G00 α Xx2 Yy2 Dr2;………….compensation No. change

N103 Xx3 Yy3;
