Total Access 600 Series User Manual © 2002, ADTRAN, Inc.
Total Access 600 Series SHDSL IAD User Interface Guide/64200683L1-31B
Page 50
Send/Check 2047
Sends and checks a 2047 BERT pattern over the network interface (assuming LTU in loopback). Results
of the test can be found in Test Results.
Send/Check ALT
Sends and checks an alternating pattern over the network interface (assuming LTU in loopback). Results
of the test can be found in Test Results.
Status
Signal State
Internal ADTRAN use.
Data Rate
Rate at which the WAN has connected.
Frame Mode
Framing mode.
G.hs State
Internal ADTRAN use.
G.hs Event
Internal ADTRAN use.
>FXS
Refer to the Total Access 600 Series FXS Voice Ports User Interface Guide.
>EC/ADPCM
Refer to the Total Access 600 Series FXS Voice Ports User Interface Guide.
