Advanced Energy Thyro-PX User Manual

Table 3‑2. Type Range 500 Volts (Continued)
Model
Type Current (A)
Dimensions (WxHxD)
mm (in)
Weight
kg (lb)
Dimensional
Drawing
350 HF ,495 HF, 650 HF 348 (10.8) 525 (20.7) 340 (13.4) 30 (66.1) Figure 5‑18
780 HF, 1000 HF, 1500
HF
575 (22.6) 787 (31.0) 505 (19.9) 74 (163.1) Figure 5‑19
1850 HF 550 (21.6) 1094 (43.1) 445 (17.5) 119 (262.3) Figure 5‑20
2600 HF 593 (23.3) 1094 (43.1) 474 (18.6) 152 (335.1) Figure 5‑21
Table 3‑3. Type Range 690 Volts
Model
Type Current (A)
Dimensions (WxHxD)
mm (in)
Weight
kg (lb)
Dimensional
Drawing
Thyro-PX 1PX
80 H 200 (7.9) 320 (12.6) 232 (9.1) 8 (17.6) Figure 5‑2
200 HF 200 (7.9) 370 (14.6) 232 (9.1) 9 (19.8) Figure 5‑3
300 HF, 500 HF 175 (6.9) 501 (19.7) 340 (13.4) 15 (33.0) Figure 5‑4
780 HF, 1400 HF 242 (9.5) 787 (31.0) 505 (19.9) 35 (77.2) Figure 5‑5
2000 HF 522 (20.5) 577 (22.7) 445 (17.5) 50 (110.2) Figure 5‑6
2600 HF 593 (23.3) 577 (22.7) 473 (18.6) 62 (136.7) Figure 5‑7
Thyro-PX 2PX
80 H 325 (12.8) 320 (12.6) 232 (9.1) 12 (26.5) Figure 5‑9
200 HF 325 (12.8) 415 (16.3 232 (9.1) 15 (33.0) Figure 5‑10
300 HF, 500 HF 261 (10.3) 501 (19.7) 340 (13.4) 22 (48.5) Figure 5‑11
780 HF, 1400 HF 410 (16.1) 787 (31.0) 505 (19.9) 54 (119.0) Figure 5‑12
1850 HF 550 (21.6) 837 (33.0) 445 (17.5) 84 (185.2) Figure 5‑13
2400 HF 593 (23.3) 837 (33.0) 474 (18.6) 107 (235.9) Figure 5‑14
Thyro-PX 3PX
80 H 450 (17.7) 320 (12.6) 232 (9.1) 17 (37.5) Figure 5‑16
200 HF 450 (17.7) 414 (16.4) 232 (9.1) 20 (44.0) Figure 5‑17
300 HF, 500 HF 348 (10.8) 525 (20.7) 340 (13.4) 30 (66.1) Figure 5‑18
780 HF, 1400 HF 575 (22.6) 787 (31.0) 505 (19.9) 74 (163.1) Figure 5‑19
1700 HF 550 (21.6) 1094 (43.1) 445 (17.5) 119 (262.3) Figure 5‑20
2200 HF 593 (23.3) 1094 (43.1) 474 (18.6) 152 (335.1) Figure 5‑21
Advanced Energy
®
Thyro-PX
®
Power Controller
57010148-00G Specifications 3‑3
