Advanced Energy Thyro-PX User Manual

Table 3‑5. Type voltage 500 volts (Continued)
Model
Type Current
(A)
Type Power
(kVA)
Dissipation
(W)
Current
Transformer
T1
Burden
R (Ω)
Fuse F1
(A)
2600 HF 2251 8700 3000/1 1.00 4x1500
Table 3‑6. Type voltage 690 volts
Model
Type Current
(A)
Type Power
(kVA)
Dissipation
(W)
Current
Transformer
T1
Burden R
(Ω)
Fuse F1 (A)
Thyro-PX 1PX
80 H 55 125 100/1 1.2 100
200 HF 138 260 200/1 1.0 250
300 HF 207 360 300/1 1.0 350
500 HF 345 625 500/1 1.0 630
780 HF 538 910 1000/1 1.2 2x630
1400 HF 966 1900 1500/1 1.0 4x700
2000 HF 1380 3200 2000/1 1.0 4x900
2600 HF 1794 3450 3000/1 1.2 4x1400
Thyro-PX 2PX
80 H 95 225 100/1 1.2 100
200 HF 239 485 200/1 1.0 250
300 HF 358 640 300/1 1.0 350
500 HF 597 1225 500/1 1.0 630
780 HF 932 1700 1000/1 1.2 2x630
1400 HF 1673 3750 1500/1 1.0 4x700
1850 HF 2210 5700 2000/1 1.0 4x900
2400 HF 2868 6400 3000/1 1.2 4x1400
Thyro-PX 3PX
80 H 95 350 100/1 1.2 100
200 HF 239 740 200/1 1.0 250
300 HF 358 1020 300/1 1.0 350
500 HF 597 1825 500/1 1.0 630
780 HF 932 2740 1000/1 1.2 2x630
1400 HF 1673 5600 1500/1 1.0 4x700
1700 HF 2031 8000 2000/1 1.0 4x900
