Advanced Energy Thyro-PX User Manual

Table 4‑4. 9-pin analog I/O connector (X52)
Pin Signal Name Function
X52.1 + 5 V
X52.2 Analog input 1.1 Setpoint power controller 1
X52.3 Analog input 1.2 Setpoint power controller 2
X52.4 Analog input 1.3 Setpoint power controller 3
X52.5 Common
X52.6 Analog output 1.1 Output power controller 1
X52.7 Analog output 1.2 Output power controller 2
X52.8 Analog output 1.3 Output power controller 3
X52.9 Common
Table 4‑5. 16-pin analog/digital I/O connector (X53 or X54)
Pin Signal Name Function
X53.1 + 24 V
X53.2 + 24 V
X53.3 Digital input 2.1 User configured
X53.4 Digital input 2.2 User configured
X53.5 Digital input 2.3 User configured
X53.6 Digital input 2.4 User configured
X53.7 Common
X53.8 Digital output 2.1 User configured
X53.9 Digital output 2.2 User configured
X53.10 Digital output 2.3 User configured
X53.11 Common
X53.12 + 5 V
X53.13 Analog input 2.1 User configured
X53.14 Analog input 2.2 User configured
X53.15 Analog input 2.3 User configured
X53.16 Common
Table 4‑6. 16-pin digital I/O connector (X53 or X54)
Pin Signal Name Function
X54.1 + 24 V
X54.2 + 24 V
X54.3 Digital input 3.1 User configured
Advanced Energy
®
Thyro-PX
®
Power Controller
57010148-00G Communication Controls 4‑7
