SMD23E2 & SMD24E2 SPECIFICATIONS
SMD23E2 and SMD24E2 User’s Manual
ADVANCED MICRO CONTROLS INC.
12
The SMD23E2 and SMD24E2 Families (continued)
Part Numbering System
Figure R1.2 Part Numbering System
General Functionality
Each member of the SMD23E2 and SMD24E2 families has three integrated parts:
An indexer that accepts commands over an Ethernet connection using the EtherNet/IP, PROFINET, or
Modbus TCP protocols
A 3.4 Arms micro-stepping driver that accepts 24 to 48 Vdc as its input power source
A high torque size 23 or size 24 stepper motor (130, 240, or 350 oz-in holding torque).
An incremental or absolute multi-turn encoder is also available for applications that require position feedback
or verification.
The availability of the EtherNet/IP, PROFINET, and Modbus TCP protocols makes the
SMD23E2 and
SMD24E2
units easy to integrate into a wide variety of control systems. This combination of host and driver
gives you several advantages:
Sophisticated I/O processing can be performed in the host (PLC or other controller) before sending
commands to the
SMD23E2 or SMD24E2
unit
All motion logic is programmed in the host, eliminating the need to learn a separate motion control
language
The integral two port Ethernet switch simplifies network cabling
The DLR interface eliminates single point failures in EtherNet/IP environments
The MRP interface eliminates single point failures in redundant PROFINET environments
The elimination of the separate indexer and driver lowers total system cost.
An
SMD23E2 or SMD24E2
is powered by a nominal 24 to 48 Vdc power source, and can accept surge
voltages of up to 60 Vdc without damage. The output motor current is fully programmable from 1.0 Arms to
3.4 Arms which makes the
SMD23E2 and SMD24E2
units suitable to a wide range of applications. In addi-
tion to the Motor Current setting, the Motor Steps per Turn, Idle Current Reduction, and Anti-Resonance Cir-
cuit features are also fully programmable. If you have used other stepper indexer products from AMCI, you
will find programming an
SMD23E2 or SMD24E2
to be very similar to these products.
The
SMD23E2 and SMD24E2
contains a true RMS motor current control driver. This means that you will
always receive the motor’s rated torque regardless of the Motor Steps/Turn setting. (Drivers that control the
peak current to the motor experience a 30% decrease in motor torque when microstepping a motor.) The
combination of an ultra-low inductance motor and a high-power, true RMS driver gives unprecedented torque
vs. speed performance for any DC application.
Network: (2) 4 pin Female D-Type
Power: (1) 5 pin Male A-Type
IP50 Rating
‘-M12S’ = M12 Connectors, Shaft Seal
Network: (2) 4 pin Female D-Type
Power: (1) 5 pin Male A-Type
IP64 Rating
‘-M12P’ = M12 Connectors, Sealed Body
Network: (2) 4 pin Female D-Type
Power: (1) 5 pin Male A-Type
IP67 Rating
M12 Connectors
SM
2
–
FRAME
23 = Size 23 Frame
24 = Size 24 Frame
FACTORY DEFAULT PROTOCOL
E = EtherNet/IP
A = PROFINET
Every device can be configured for:
EtherNet/IP, PROFINET, or Modbus TCP
ENCODER
‘blank’ = No encoder
A = Absolute Multi-turn Encoder
2,048 counts/turn.
E = Incremental Encoder
4,096 counts/turn max.
TORQUE
Size 23 Frame
130 = 130 oz-in
240 = 240 oz-in
Size 24 Frame
350 = 350 oz-in
