Advanced Quick Zone XL User Manual

43
Twin Wire Sounder Circuit Functional Options
If using Twin Wire zones (see page 18 for details of setting Twin Wire zones), the sounders on each of the Twin
Wire circuits can be programmed with a custom response to various panel functions in the same way as the
relays and switched -ve outputs (page 40).
The process is exactly the same as with the relays & switched -ve outputs, but using the above code.
I.e. Use button 1 to select the Twin Wire sounder circuit first (indicated by a steady fire zone LED), press
ENTER and then use button 1 to select the function that requires editing for that sounder circuit (indicated by a
pulsing fire zone LED) as per table below.
Use button 2 to edit the response indicated by the amber, fault / disabled / test LED, ON or OFF.
Fire LED
(pulsing)
LED 1
LED 2
LED 3
LED 4
LED 5
Function
Silences on
Silence
Alarms
Sounds on
Evacuate
Sounds on
Class
Change
Sounds on
Alert
Sounds
During Delay
Amber fault
LED
(default
setting)
ON
ON
ON
ON
OFF
Press the ENTER button to return back to the Twin Wire sounder circuit selection, indicated by a steady zone
fire LED.
When finished, press and hold Button 1 for 3 seconds to save setting and exit programming mode.
Conventional Sounder Circuit Functional Options
To programme each of the conventional sounder circuits on the main circuit
board and high spec zone extension cards with same custom responses as above, the process is exactly the
same but using the code 4-3-4-4.
I.e. Use button 1 to select the sounder circuit first (indicated by a steady fire zone LED) as per table below.
LED 1
LED 2
LED 3
LED 4
LED 5
LED 6
SNDR1
(Main
PCB)
SNDR2
(Main
PCB)
SNDR A.
Zone ext card 1
(Zones 5 - 8)
SNDR B.
Zone ext card 1
(Zones 5 - 8)
SNDR A.
Zone ext card 2
(Zones 9 - 12)
SNDR B.
Zone ext card 2
(Zones 9 - 12)
Press ENTER and then use button 1 to select the function that requires editing for that sounder circuit (indicated
by a pulsing fire zone LED) as per the sounder CCT function table in the Twin Wire settings above.
Use button 2 to edit the response indicated by the amber, fault / disabled / test LED, ON or OFF.
Press the ENTER button to return back to the sounder circuit selection, indicated by a steady zone fire LED.
When finished, press and hold Button 1 for 3 seconds to save setting and exit programming mode.
Sounder CCT
function table
