AdvanPOS WP-T800 - Setting

WP-T800 1 Station Thermal Line Printer
- 15 -
5.3 Setting
Please use screw driver to unlock the DIP switch cover at the bottom, open it as
shown on picture right side and it shows DIP switch
DIP1 & DIP2
Settings as below
(1).Select Handshaking Control
SW1-3 Handshaking Control
OFF DTR/DSR
ON XON/XOFF
(2). Select Data Length
SW1-4 Data Length
OFF 8 Bit
ON 7 Bit
(3). Select Parity Check
SW1-5 Parity Check
OFF No
ON Yes
(4). Select Parity Type
SW1-6 Parity Type
OFF Odd
ON Even
