Advantech Adam 4000 Series User Manual

Chapter 4 Command Set 4-21
Chapter 4
Command Syntex
Command
Response
Syntex
Command Description
Command
Example
Command
response
Example
#AA(cr) >(data0)(data1-
)(data2)(data3-
)(data4)(data5)
(cr)
data0 ~ 5:
snnnnnn
s : + or
-n : digit or dot
Read Analog Input (for all 8
ch)When over range the (data
n) will
show>+999999(cr)When under
range the (data n) will show>-
999999(cr)When burn-out the
(data) will show>+888888(cr)
#03(cr) >+05.000-04.9-
00 +100.23-
089.32
+09.123
+123.45-09.13-
4(cr)(channel 5
be disable)
$AA0Ci(cr)i: 0 ~ 7
channel number
!AA(cr) Gain error calibrate of
assignment channel, User
have to input the external
standard source for calibrating
process
$050C7(cr) !05(cr)
$AA1Ci(cr)i: 0 ~ 7
channel number
!AA(cr) Offset error calibrate of
assignment channel, User
have to input the external
standard source for calibrating
process
$031C5(cr) !03(cr)
$AA2(cr) !AATTCCFF(cr) The command requests the
return of the configuration
data from the analog input
module at address AA
$062(cr) !06FF0600(cr)
$AA5VV(cr)VV: 00 ~
FF each bit for each
channel
!AA(cr) Channel enable/disable setting $03507(cr)-
ex. 07 mean
channel 0,1
and 2 is
enable and
others will
be disable
!03(cr)
$AA6(cr) !AAVV(cr)
VV: 00 ~ FF
Get the channel enable/
disable status
$036(cr) !0307(cr)
$AAF(cr) !AA(version)(c-
r)version :
A1.0
The command requests the
module at address AA to
return the version code of
module firmware
$03F(cr) !03A1.0(cr)
