Advantech Adam 4000 Series User Manual

Chapter 4 Command Set 4-77
Chapter 4
4014D
Command Syntax Command Name Description
I/O
Module
$AA3 Read Source
High/Low Values
for Linear Mapping
Read the high/low limit values
from the specified module for
linear mapping.
4014D
$AA5 Read Target
High/Low Values for
Linear Mapping
Read the mapped input high/ low
limit values from the specified
module for linear mapping.
4014D
$AA6
(data_A)(data_B)
Write Source
High/Low Values for
Linear Mapping
Write the high/low limit values to
the specified module for linear
mapping.
The module will only activate the
source values after new target
high/low values are written
(Command $AA7).
4014D
$AA7
(data_C)(data_D)
Write Target
High/Low Values for
Linear Mapping
Write the mapped input high/ low
limit values to a specified module
for linear mapping.
This command is only valid if its
was preceded by a $AA6
command.
4014D
$AAAV Enable/Disable
Linear Mapping
Enables or disables the linear
mapping function of the specified
analog input module.
4014D
$AA8V Select LED Data
Origin
Select whether LED will display
data from the input module
directly or from the host PC
4014D
$AA9(sign_data) Send LED Data The PC sends data to the
module’s LED display. This
command is valid only after
selectting LED to display from PC
($AA8V)
4014D
