Advantech Adam 4000 Series User Manual

Technical specifications
A-12 ADAM 4000 Series User's Manual
A.5 ADAM-4014D Analog Input Module with LED Display
Table A-7 ADAM-4014D Specifications
Input range ±150 mV, ±500mV,
±1 V, ±5 V, ±10 V and ±20mA
Output RS-485 (2-wire)
Speed (bps) 1200, 2400, 4800, 9600, 19.2K, 38.4K
Maximum distance 4000 ft. (1200 m)
Isolation voltage 500V
DC
Sampling rate 10 samples/sec
Bandwidth 4 Hz
Accuracy ±0.05% or better
Zero drift ±6 µV/ °C
Span drift ±25 ppm /
o
C
CMR @ 50/60 Hz 150 dB
NMR @ 50/60 Hz 100 dB
Isolated loop power +15 VDC @ 30 mA
Input impedance 40 KΩ
LED indicator 4½ -digit readout
Digital input 1 channel
logic level 0 +1 V max.
logic level 1 +3.5 to +30 V
pull up current 0.5 mA, 10 K resistor to +5 V
Event counter
Max. input frequency 50 Hz
Min. pulse width 0.5 msec
Digital output 2 channels open collector to 30 V
sink current 30 mA max. load
power dissipation 300 mW
Watchdog timer Yes
Power requirements +10 to +30 V
DC
(non-regulated)
Power consumption 1.8 W
