Technical specifications
A-10 ADAM 4000 Series User's Manual
Table A-6 ADAM-4013 Specifications
Input range Pt and Ni RTD
Output RS-485 (2-Wire)
speed (in bps) 1200, 2400, 4800, 9600, 19.2K, 38.4K
maximum distance 4000 ft. (1200 m.)
Accuracy ±0.05% or better
Zero drift ±0.01 °C/ °C
Span drift ±0.01 °C/ °C
Input connections 2, 3, or 4 wires
Isolation-rated voltage 3000 V
DC
CMR @ 50/60 Hz 150 dB
NMR @ 50/60 Hz 100 dB
Bandwidth 4 Hz
Conversion rate 10 samples/sec.
Input impedance 2 MΩ
Watchdog timer Yes
Power supply +10 to +30 V
DC
(non-regulated)
Power consumption 0.7 W
A.4 ADAM-4013 RTD Input Module
