4-46 ADAM 4000 Series User's Manual
Table 4-1 Input Range Codes (Type Code)
Input Range Code (Hex) Input Range for 4011,4011D,4018,4018+,4018M
00 ± 15 mV
01 ± 50 mV
02 ± 100 mV
03 ± 500 mV
04 ± 1 V
05 ± 2.5 V
06 ± 20 mA
1
0E Type J Thermocouple 0
o
to 760
o
C
0F Type K Thermocouple 0
o
to 1370
o
C
10 Type T Thermocouple -100
o
to 400
o
C
11 Type E Thermocouple 0
o
to 1370
o
C
12 Type R Thermocouple 500
o
to 1750
o
C
13 Type S Thermocouple 500
o
to 1750
o
C
14 Type B Thermocouple 500
o
to 1800
o
C
Input Range Code(Hex) Input Range for 4012,4017,4017+
08 ± 10 V
09 ± 5 V
0A ± 1 V
0B ± 500 mV
0C ± 150 mV
0D ± 20 mA
1
Note
1
: The input range requires the useage of a 125 Ω current conversion
resistor
(continued on following page)
4011, 4011D, 4012, 4013, 4015, 4016,
4017, 4017+, 4018, 4018+, 4018M, 4019
