4-68 ADAM 4000 Series User's Manual
Command Set
ADAM-4015 command codes against Input ranges table
IEC RTD 100O, α = 0.00385
JIS RTD 100O, α = 0.00391
Command Code (Hex) Input Type Input Range
20 Platinum 100 (IEC) -50 C to 150 C
21 Platinum 100 (IEC) 0 C to 100 C
22 Platinum 100 (IEC) 0 C to 200 C
23 Platinum 100 (IEC) 0 C to 400 C
24 Platinum 100 (IEC) -200 C to 200 C
25 Platinum 100 (JIS) -50 C to 150 C
26 Platinum 100 (JIS) 0 C to 100 C
27 Platinum 100 (JIS) 0 C to 200 C
28 Platinum 100 (JIS) 0 C to 400 C
29 Platinum 100 (JIS) -200 C to 200 C
2A Platinum 1000 -40 C to 160 C
2B BALCO 500 -30 C to 120 C
2C Ni 604 -80 C to 100 C
2D Ni 604 0 C to 100 C
