Advantech Adam 4000 Series User Manual

Appendix A Technical Specifications A-35
Appendix A
Figure A-15 ADAM-4080 Function Diagram
Rect
& Filter
Power
Converter
Power Input +10 ~ +30 V
DC
MICRO CONTROLLER
RS-485 COMMUNICATION
EEPROM
#
CONFIG DATA
#
LARM SETTING
DATA+ DATA-
PROGRAMMABLE DIGITAL NOISE FILTER
RESET
2 CHANNEL DIGITAL OUTPUT
ALARM 0
ALARM 1
COUNTER 0
COUNTER 1
PHTO/TTL INPUT SELECT AND GATE CONTROL
PROGRAMMABLE THRESHOLD
VOLTAGE
CH0 (TTL) CH1 (TTL)
GATE1 (TTL)
GATE0 +
CH1 +
CH1 - CH0 +
CH0 -
GATE0 -
GATE1 +
GATE1 -
GATE0 (TTL)
+5V
+5V +5V
+5V
