Appendix B Data Formats and I/O Ranges B-9
Range
Code
(hex)
Input
Range
Description
Data Formats +F.S. Zero -F.S.
Displayed
Resolution
08 – 10 mV
Engineering
Unite
+10.000 –00.000 -10.000 1 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
09 – 5V
Engineering
Unite
+5.0000 –0.0000 -5.0000 100.00 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
0A – 1V
Engineering
Unite
+1.0000 –0.0000 -1.000 100.00 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
0B – 500 mV
Engineering
Unite
+500.00 –000.00 -500.00 10 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
0C – 150 mV
Engineering
Unite
+150.00 –000.00 -150.00 10 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
0D – 20 mV
Engineering
Unite
+20.000 –00.000 -20.000 1 v
%ofFSR +100.00 –000.00 -100.00 0.01%
Two s
Complement
7FFF 0000 8000 1 LSB
1
Range
Code
(hex)
Input Range
Description
Data Formats
Maximum
Specitied
Signal
Minimum
Specitied
Signal
Displayed
Resolution
0E
Type J
Thermocouple
0Cto760C
Engineering
Unite
+760.000 +000.00
0.01 C
% of FSR +100.00 +000.00 0.01%
Two s
Complement
7FFF 0000 1 LSB
1
