23 MIC-770 V2 User Manual

Chapter 2 H/W Installation

3. Remove baffle cover.

4. Assemble module on M/B (Note: Optional expansion modules need to connect

with a cable. (Please refer to MB internal I/O connector specification at IO con-

nector page for GPIO connector.)

5. Assemble module baffle with screws.

6. Replace bottom cover and secure with screws.
