PPC-L127T User Manual 6
• Relative humidity: 10 ~ 95% @ 40° C (non-condensing)
• Shock: 10 G peak acceleration (11 ms duration)
• Certification: EMC: CE, FCC, BSMI. Safety: UL 60950, CB, CCC,
BSMI
• Vibration: 5 ~ 500 Hz 1 G RMS Random vibration
1.3 LCD Specifications
• Display type: 12.1" TFT LCD
• Max. resolution: 800 x 600
• Colors: 262 K
• Dot size (mm): 0.3075 x 0.3075
• Viewing angle: 70° (left), 70° (right), 60° (up), 50° (down)
• Luminance: 400 cd/m
2
• Temperature: -10 ~ 65° C
• *VR control: Brightness
• Backlight lifetime: 50,000 hours
* The VR control is defined by hot key in DOS or BIOS mode as
below: Ctrl-Alt-F3, Ctrl-Alt-F4.
Note: The color LCD display installed in the panel PC
is high-quality and reliable. However, it may
contain a few defective pixels which do not
always illuminate. With current technology, it is
impossible to completely eliminate defective
pixels. Advantech is actively working to improve
this technology.
