PPC-L127T User Manual
30
A.6 COM4 RS-232 serial port (CN23)
A.7 Parallel Port Connector (CN29)
T
able A.6: COM
3 RS-232 serial p
ort (CN23)
Pin
Signal
Pin
Signal
1
DCD
2
RXD
3T
x
D
4
D
T
R
5
GND
6
DSR
7
RTS
8
CTS
9
RI
T
able A.7: Parallel
Port Connect
or (CN29)
Pin
Signal
Pin
Signal
1
STROBE*
2
D0
3D
1
4
D
2
5
D3
6
D4
7D
5
8
D
6
9
D7
10
ACK*
1
1
BUSY
12
PE
13
SLCT
14
AUTOFD*
15
ERR*
16
INIT*
17
SLCTINI*
18
GND
19
GND
20
GND
21
GND
22
GND
23
GND
24
GND
25
GND
*Low active
