31 Appendix A
A.8 VGA Connector (CN2)
Table A.8: VGA connector (CN2)
Pin Signal
1 RED
2 GREEN
3 BLUE
4N/A
5 GND
6GND
7 GND
8GND
9 N/A
10 GND
11 N/A
12 SPDAT
13 HSYNC
14 VSYNC
15 SPCLK
