Advantech PPC-L127T User Manual

PPC-L127T User Manual 12
Figure 2.4: Bottom view of the panel PC
2.2 Installation Procedures
2.2.1 Connecting the power cord (Optional item: PS-
DC19-L60)
The panel PC can only be powered by a DC electrical outlet. Be sure to
always handle the power cords by holding the plug ends only. Please fol-
low the Figure 2-5 to connect the male plug of the power cord to the DC
inlet of the panel PC.
2.2.2 Connecting the keyboard or mouse
Before you start the computer, please connect the Y-shaped adaptor to the
PS/2 mouse and keyboard port on the I/O section of the panel PC, then
connect the necessary mouse or keyboard to the Y-shaped adapter or
serial ports.
2.2.3 Switching on the power
When you look at the rear side of the panel PC, you will see the power
switch as shown in Figure 2-2.
Battery
Door Cover
