PPC-L127T User Manual 24
4.1.3 Locating jumpers and connectors
Figure 4.1: Jumpers and Connectors on the PPC-L127T motherboard
CN33CN7CN6
CN5
CN11
CN13
CN12
SLOT1
CN17
CN9
CN25
CN4
CN3
JP1
JP3
JP2
J1
