19 Chapter 3
hard drive, with Pin 1 on the cable corresponding to Pin 1 on the
hard drive.
5. Put the plastic rear cover on and tighten the screws.
Figure 3.1: Installing primary 2.5" HDD
Plastic rear cover
2.5” HDD
Metal brace
