SIMB-982 User Manual 56
A.24 CPU FAN Header (CPUFAN1)
Pin Signal
1GND
2 CPU FAN VCC
3 CPU FAN SPEED
4 CPU FAN PWM
A.25 SYSTEM FAN Header (SYSFAN1 / SYSFAN2)
Pin Signal
1GND
2
SYS FAN VCC
3
SYS FAN SPEED
4
SYS FAN PWM
