Advantech WISE-4000 Series User Manual

97 WISE-4000 User Manual
Appendix A I/O Modbus Mapping Table
40201 0
AI Type Code**
(The type codes of channels for
average value can't be changed.)
Read/Write
40202 1 Read/Write
40203 2 Read/Write
40204 3 Read/Write
40205 Average Ch 0~3 Read
* AI Status (2 Registers)
Lower Register Higher Register
Bit Description Bit Description
0 Fail to Provide AI Value 0 DI triggered to Safety Value
1 Over Range 1 DI triggered to Startup Value
2 Under Range 2 Reserved
3 Open Circuit / Burnout 3 Reserved
4 Reserved 4 Reserved
5 Reserved 5 Reserved
6 Reserved 6 Reserved
7 ADC Initializing/Error 7 Reserved
8 Reserved 8 Reserved
9 Zero/Span Calibration Error 9 Reserved
10 Reserved 10 Reserved
11 Reserved 11 Reserved
12 Reserved 12 Reserved
13 Reserved 13 Reserved
14 Reserved 14 Reserved
15 Reserved 15 Reserved
** AI Type Code (2 Registers)
Type Code Input Range
0x1080 4~20 mA
0x1082 0~20 mA
