105 WISE-4000 User Manual
Appendix A I/O Modbus Mapping Table
A.6 WISE-4012 Wireless Modbus Mapping Table
Address 0X Channel Description Attribute
00001 0
DI Value
Read
00002 1 Read
00003 2 Read
00004 3 Read
00017 0
DO Value
R/W
00018 1 R/W
00033 0
Counter Status
(0: stop
1: start)
R/W
00034 1 R/W
00035 2 R/W
00036 3 R/W
00037 0
Clear Counter
(1: write to clear value)
Write
00038 1 Write
00039 2 Write
00040 3 Write
00041 0
Clear Overflow
(1: counter overflow,
auto set to 0 after read)
R/W
00042 1 R/W
00043 2 R/W
00044 3 R/W
00045 0
DI Latch Status
(1: DI latched,
0: write to clear latch)
R/W
00046 1 R/W
00047 2 R/W
00048 3 R/W
00101 0
Reset Historical
Maximum AI Value
Write
00102 1 Write
00103 2 Write
00104 3 Write
00105
Average
Channel 0~3
Write
00111 0
Reset Historical
Minimum AI Value
Write
00112 1 Write
00113 2 Write
00114 3 Write
00115
Average
Channel 0~3
Write
