8 - Specifications
8.1 - Operating Specifications
The table below specifies the recommended operating conditions for a PixLite 16 Mk2
controller.
Parameter Value/Range Units
Input Voltage Range 5-24 V DC
Max Current Per Power Bank 32 A
Max Logic Current Consumption @ 5V 150 mA
Fan Output Max Power 15 W
Recommended
Ambient Temperature
1
-20 to +50 °C
Absolute Maximum Temperature
of PCB Components
-40 to +80 °C
Maximum Current Per Pixel Output 7.5 A
1 Suggested limit only, the component temperatures must be kept within their absolute maximum ratings.
Monitoring the component temperatures with the Advatek Assistant software is recommended.
8.2 - Mechanical Specifications
The control board dimensions and locations of all mounting holes are shown in Figure
13 below. There are 6 x 3mm mounting holes, and 4 x 4mm mounting holes. The 4 x
4mm holes will allow the board to be mounted directly into a CG-1500 enclosure.

Advatek Lights PixLite 16 Mk2 Specifications

General

Brand	Advatek Lights
Model	PixLite 16 Mk2
Category	Controller
Language	English
