9 - Troubleshooting
Generally, troubleshooting requires looking at the LEDs on the control board.
9.1 - LEDCodes
Please refer to the table below for condition codes for the onboard status and power
LEDs.
Status LED(Red) Power LED(Green) Condition
Flashing Solid
Normal operation,
Main application running okay
Slow flashing Solid Test mode running
Flashing together Flashing together
Looking for IP address
(DHCPMode)
Solid Solid Main application not running
Off Solid Main application not running
Solid Off Main application not running
Alternate flashing Alternate flashing Bootloader mode
Off Off No power
Please refer to the table below for condition codes for the Ethernet jack status LEDs.
Link LED (Green) Data LED (Yellow) Condition
Solid Flashing Connected okay, receiving data
Solid Off Connected okay, no data
Off Off No link established
9.2 - No Power/Status LEDs
Ensure that your power supply is supplying correct voltage as per Section 4.1 .
Additionally, ensure that it can supply enough current to drive the lights that are
connected. You should also try disconnecting all outputs and see if the controller then
turns on. If the supplied power is correct, try performing a recovery firmware update
as per Section 7.2.
