21
COMMON USER CODES FOR OUTPUT 1 & 2 (Locations 03 & 04)
The Common User Codes 1 and 2 are prepared for operating of the Output 1 and 2 respectively as an
enhance code. The Common User Codes MUST work in the form of “Card + Common Code” to
operate the outputs to increase the security of the access control system. See Media 4 at Locations 10
& 20 for more information.
NOTE: Common User Code alone can NOT operate the Outputs directly.
LOCATIONS COMMON USER CODE VALIDATION
(1) LOCATIONS
-- Location Stores The Common User Code for Output 1
-- Location Stores The Common User Code for Output 2
(2) COMMON USER CODES
The Common User Code can be 4 to 8 digits.
When a new Common User Code is keyed in and confirmed, the old one is replaced.
(3) VALIDATION
Pressing key to confirm code entry.
Example:
a) Set a Common User Code “1 3 5 7” for Output 1 ----
b) Deleted a Common User Code from memory: Key in the Location number and #. ----
4 to 8 Digits
-
(1) (2)
(3)
To Next Page
