AEI DK-2822 - Output Mode and Timing Settings; Reset Output Timer with Super User Code

31
OUTPUT MODE & TIMING FOR OUTPUT 1 & 2 (Locations 51 & 52)
The two relay outputs are programmable for Start/Stop or Timing modes. Apart from door access
control, alarm arm-disarm control, they are also universal timers for automatic operators in
industry with their 99,999 seconds (over 24 hours) programmable timer.
(1) LOCATIONS
-- Location for Output 1
-- Location for Output 2 (DK-2822A only)
(2) OUTPUT MODE & TIMING
 Start /Stop Mode (Toggle)
The number 0 sets the output to Start / Stop mode. The output Starts when an User Code
and/or Card is entered/read; the output Stops when an User Code and/or Card is
entered/read again.
-- Seconds Momentary --- (Default -- Momentary 5 Seconds)
The output can be set in Momentary Mode with the time of 1 second to
99,999 seconds. The output will reset automatically when the time
expires.
(3) VALIDATION
Press key once. Two-beep confirms the entry.
RESET OUTPUT TIMER WITH SUPER USER CODE
The Output Timer can be RESET manually at anytime with the Super User Code that operates
the desired output before the end of the time.
Example:
Reset Output 1 Timer -- ------------- Output 1 stops
Reset Output 2 Timer -- ------------- Output 2 stops
SUPER USER CODE
SUPER USER CODE
OUTPUT MODE & TIME VALIDATIONLOCATIONS

-
 
or

-
 
(3)(2)(1)
