AEI DK-2822 - Wiegand Data Output Format; Wiegand Format for EM Card & User Code

45
- 34 - Bit Wiegand Data Output
Bit 1 : Even Parity Bit (bit 2 – bit 17)
Bit 2 – Bit 33 : 32 Bit ID Number
Bit 34 : Odd Parity Bit (bit 18 – bit 33)
- 37 - Bit Wiegand Data Output
Bit 1 : Even Parity Bit (bit 2 – bit 19)
Bit 2 – Bit 36 : 35 Bit ID Number
Bit 37 : Odd Parity Bit (bit 19 – bit 36)
(3) VALIDATION
Press

key once. Two-beep confirms the entry
(1) LOCATION
Key in Location
(2) WIEGAND FORMAT FOR EM CARD & USER CODE
The Wiegand data output is programmable for 26-bit, 34-bit or 37-bit standard format.
- 26 - Bit Wiegand Data Output (Default)
Bit 1 : Even Parity Bit (bit 2 – bit 13)
Bit 2 – Bit 25 : 24 Bit ID Number
Bit 26 : Odd Parity Bit (bit 14 – bit 25)

WIEGAND FORMAT VALIDATIONLOCATION

, or



(2) (3)(1)



WIEGAND DATA OUTPUT FORMAT (Location 93)
