PROGRAMMING SUMMARY CHART
LOCATION
FUNCTION
ENTRY LIMITS & CODE
OPTIONS
CODE ENTRY
FACTORY
DEFAULT
0 1
Master Code 4-8 Digits


MASTER CODE


NIL
0 2
Super User
Code
4-8 Digits


SUPER USER CODE


NIL
0 3
Common User
Code
for
O/P 1
4-8 Digits


COMMON USER CODE 1


NIL
0 4
Common User
Code
for
O/P 2


COMMON USER CODE 2


NIL

1 0
User Codes / Cards for
O/P 1
CODE 1
- MEDIA:
1---EM Card
2---Private User Code
3---EM Card+Sec User Code
4---EM Card+Com User Code
5---Deletion of User Code
CODE 2
- USER ID:
000-999---Group 1(10)
001-100---Group 2(20)
CODE 3
- USER CODES /
Cards: 4-8 Digits / Cards


CODE1

CODE2

CODE3


NIL
2 0
User Codes / Cards for
O/P 2


CODE1

CODE2

CODE3


NIL

4 0
Visitor Codes
CODE 1
- VISITOR ID:
01-50
CODE 2
- VALID PERIOD:
00---One Time
01-99 Hours
CODE 3
- VISITOR CODE:
4-8 Digits


CODE1

CODE2

CODE3


NIL
4 1
Duress Code for O/P 1
CODE ID
- O/P 1: 01-50
CODE ID
- O/P 2:
01-10
DURESS CODE: 4-8 Digits


CODE ID
DURESS CODE
CODE ID


NIL
4 2
Duress Code for O/P 2

 

NIL
 
5 1
O/P Mode for O/P 1
OUTPUT MODE & TIME:
0--- Start / Stop
1---99999 Seconds,
START TIME:
00:00-23:59
STOP TIME:
00:00-23:59
5 6
Start & Stop Times
for Inhibition

STOP TIMESTART TIME

NIL
CURRENT REAL TIME:
00:00-23:59
5 5
Real-Time-Clock

CURRENT TIME

NIL
Momentary


O/P MODE & TIME


5 Seconds
5 2
O/P Mode for O/P 2


O/P MODE & TIME


5 Seconds

DURESS CODE
6 0
Personal Safety &
Lock-Up
LOCK-UP CODE:
1---10 Trial, Lock-Up 60 Sec.
2---10 Trial, Activates Duress
5-10---5-10 Trial, Lock-Up 15
Minutes
00---No Lock-Up


LOCK-UP CODE


Code = 1,
10 Trials,
Lock-Up 60
Seconds
7 0
Code Entry Mode
ENTRY MODE:
1---Auto Mode
2---Manual Mode


ENTRY MODE


Mode =
2, Manual
Mode
