53
An Even Parity Bit of 0 0 0 0 = 0
An Odd Parity Bit of 0 4 D 2 = 0
An Odd Parity Bit of 0 4 D 2 = 0
An Even Parity Bit of 0 0 0 0 = 0
The 34 bits Wiegand data sending out in Binary from entry of the Code:
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0
1 1 0 1 0 0 1 0 0
The 34 bits Wiegand data sending out in Binary from entry of the Code:
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 0 0
E 0 0 0 0 0 4 D 2 O
E 0 0 0 0 0 4 D 2 O
1 1 0 1 0 0 1 0 0
B) The keyed-in Code is 1 2 3 4
The Code in Decimal Number : 1 2 3 4
The Code 1 2 3 4 Equivalent to Hex Number : 4 D 2
C) The keyed-in Code is 0 0 0 0 1 2 3 4
The Code in Decimal Number : 0 0 0 0 1 2 3 4
The Code 0 0 0 0 1 2 3 4 Equivalent to Hex Number : 4 D 2
