AEI DK-2822 - Page 55

55
Pacifier Tone ON-OFF
7 1
FUNCTION MODE:
0---NO Notification
2---2 Short Beeps
1---1 Second Long Beep
FUNCTION MODE:
0---OFF
1---ON
FUNCTION MODE:
0---OFF
1---ON

FUNCTION MODE

Mode = 1,
ON
7 2
Output Announcer

FUNCTION MODE

7 3
Standby LED Flashing

FUNCTION MODE

Mode = 1,
Flashing ON
Mode = 1
1 Second
Long Beep
Pacifier Tone
8 0
Door Forced Open
Warning & Time
FUNCTION MODE / TIME:
0---OFF
1-999 Seconds

FUNCTION / TIME

Mode = 0,
Door Forced
Open
Warning OFF
8 1
Propped-up Warning &
Time

FUNCTION / TIME

Mode = 0,
Propped-up
Warning OFF
9 0
Egress Delay Warning &
Alarm
CODE 1 - FUNCTION
MODE:
1---Momentary, No warning
2---Momentary, with
warning
3---Momentary, with
warning + Alarm
4---Hold Contact, No
warning
5---Hold Contact, with
warning
6---Hold Contact, with
warning + Alarm
CODE 2
- DELAY TIME:
0---No Delay
1-99 Seconds

CODE 1

CODE 2

Mode = 1
Momentary,
No warning
TIME = 0
No Delay
9 1
Door Opening Alarm &
TIMER
ALARM TIME:
0---No Alarm
1-999 Seconds

ALARM TIME

Time = 0,
No Alarm
1 --
2 --
3 --
4 --
9 4
Operation Mode
FUNCTION MODE:

MODE

Mode = 0
Keypad
Mode
1---Server Mode
0---Keypad Mode
9 2
DATA OUTPUT MODE
Wiegand Data Output
Disabled
Wiegand & Data Output
Enabled -- Mode “A”
Wiegand Data Output
Enabled – Mode “B”
Wiegand Data Output
Enabled – Mode “C”
Wiegand Data Output
Mode

DATA OUTPUT MODE

Mode = 1
Disabled
9 3
Wiegand Format

WIEGAND FORMAT


Format = 1
26-Bit
WIEGAND FORMAT
1 --- 26-Bit Wiegand Data
2 --- 34-Bit Wiegand Data
3 --- 37-Bit Wiegand Data
