Code Entry Limitation in Multi-User Mode due to Duress Code
The system comes with DURESS function for the user code 1 in Single User Mode and all the user codes of Group
1 in Multi-User Mode; The DURESS CODE is set up by the system automatically with the first digit of the User
Code "+2". To prevent the other User Codes fall into the Duress Code, or the Duress Codes fall into other User
Codes, the first digit of a "Stored" User code "+2" or "-2" is not allowed for the later User Code entry in
programming. The system will refuse those code entries.
An User Code 56789 was stored in the system, then 36789 and 76789 are not allowed for other
User Codes.
The system can be set to Single User Mode with the command code " and will stay in that mode until the
system is refreshed for other mode. Make sure that the Master Code was already in 4 digits before setting the
system to Single User Mode.
The system can be set to Multi Users Mode with the command code " and will stay in that mode until the
system is refreshed for other mode.
The system can be changed from Single User Mode to Multi-User Mode; or vice versa with the above operation
command codes.
When this is done, the keypad will reset itself as a fresh unit with the default values; and all the previously
programmed data will be cleared except the Master Code.
Make sure all the User Codes and Master Code are in the length of 4 Digits if the system is in Single User
Mode operation. Otherwise, code entry will not be accepted.
It is necessary to change the Master Code in the length of 4 digits first (no matter it was in 4 digits or more
than 4 digits in Multi- User Mode) before refreshing it from Multi-User Mode to Single User Mode.
The system takes approximate 2 to 3 seconds to refresh itself for the new operation mode after the command code
is entered. DO NOT enter any code during the system is being refreshed until the 2 confirmation beeps are heard.
For example:
IMPORTANT NOTES:
1)
2)
3)
Single User Mode on Duty (please wait 2-3 seconds until the confirmation
beeps are heard after the key is pressed)
Multi-User Mode on Duty (please wait 2-3 seconds until the confirmation beeps
are heard after the key is pressed)
SET THE SYSTEM TO SINGLE USER MODE
SET THE SYSTEM TO MULTI-USER MODE
REFRESH THE SYSTEM
8900"
8901"
-----
MASTER CODE
MASTER CODE
* 8900 #
#
* 8901 #
#
-----
-- WHEN IN CHANGE OF OPERATION MODE
PROGRAMMING AND USE OF THE KEYPAD -- OPERATION EXAMPLES
a)
b)
NOTE:
All programming is accomplished entirely from the front of the keypad. The keypad may be programmed in
your shop or at the installation site. Programmed information is stored in non-volatile memory so it will not
be lost if power is removed.
When programming is required. It is necessary to set the keypad into programming mode first with the
master code and validating it with key.
If the master code is forgotten, please use DAP jumper to set the keypad into programming mode.
See DAP JUMPER description in previous section for the details.
*
*
MASTER CODE
A) PROCEDURES OF PROGRAMMING
8
SPECIFICATIONS
!
!
!
!
!
!
!
!
!
!
Operation Voltage:
Operation Modes:
Input Sensing Terminals:
Relay Output Contacts:
Tamper Switch Contact:
Duress, Inter-lock & Key Active Output Rating:
Auto Refreshing Time During Code Entry:
Dimensions:
12V 24V AC/DC, No Jumper is Required for voltage selection
a) Single User Mode, Auto, or Manual Code Entry
b) Multi-User Mode -- 100 user codes for output 1 (user number 00-99), Auto or Manual Code Entry
-- 10 user codes for output 2 (user number 0-9), Auto or Manual Code Entry
-- 10 user codes for output 3 (user number 0-9), Auto or Manual Code Entry
b) Multi User Mode ----111,110,000
a) Egress Input -- Normally open referring to ( ) ground
b) Door Position Sensor Input -- Normally closed referring to ( ) ground
c) Relay 1 Stop Control -- Normally open referring to ( ) ground
OUTPUT 1: Normally Closed and Normally Open Dry Contacts, 5A / 30VDC Max. Rating
OUTPUT 2: Normally Closed and Normally Open Dry Contacts, 1A / 30VDC Max. Rating
OUTPUT 3: NPN Open Collector, 100mA Sink / 24VDC Max.
Normally Closed Dry Contact, 50mA Max.
NPN Open Collector switches to ground when active, 24VDC / 100mA Sink
a) Each Digit Maximum Entry Time Limit -- 10 seconds
b) Each Code Maximum Entry Time Limit -- 30 seconds
117(H) x 74(W)mm X 48(D)mm
: 180
-
-
-
-
User Code Combinations:
Weight
a) Single User Mode---10,000
g net
Specifications are subject to change for modification without notice
13
