AEMC 3640 User Manual

32 Digital Ground Resistance Tester Model 3640 and 4610
4.8 Continuity Measurement
ConnecttheshortingstripsbetweenXandXv(C1,P1),andY(P2)and
Z (C2).
Continuitymeasurementismadewithtwoleads,onefromX–Xv,theother
fromY–Z(P2,C2);pushthe“Measure”buttontomeasure.
Model 3640
Ω
Press To
Measure
X-Z
Xv-Y
Xv-Y
ZYX
C1 P2 C2
Fault
Hi Resistance
Hi Noise
GROUND RESISTANCE TESTER
MODEL 3640
AUTORANGING
REFER TO USER MANUAL
FOR FAULT WARNING LIGHT
EXPLANATIONS
!
®
INSTRUMENTS
Figure 18
Model 4610
Ω
Press To
Measure
X-Z
Xv-Y
Xv-Y
ZYXXv
C1 P1 P2 C2
Fault
Hi Resistance
Hi Noise
GROUND RESISTANCE TESTER
MODEL 4610
AUTORANGING
REFER TO USER MANUAL
FOR FAULT WARNING LIGHT
EXPLANATIONS
!
®
INSTRUMENTS
Figure 19
