Digital Ground Resistance Tester Model 3640 and 4610 7
2.2 4610 Control and Connector Identification
Ω
Press To
Measure
X-Z
Xv-Y
Xv-Y
ZYXXv
C1 P1 P2 C2
Fault
Hi Resistance
Hi Noise
GROUND RESISTANCE TESTER
MODEL 4610
AUTORANGING
REFER TO USER MANUAL
FOR FAULT WARNING LIGHT
EXPLANATIONS
!
2 3 4 5 6
7
891011
1
Figure 2
1. Press-to-Measurebutton
2. InputterminalX(C1)
3. InputterminalXv(P1)
4. InputterminalY(P2)
5. Groundresistanceshortinglink
6. InputterminalZ(C2)
7. Display
8. Lowbatteryindicator
9. Xv-Yhighnoiseindicator
10. Xv-Yhighresistanceindicator
11. X-Zfaultindicator
