AerAtron FR3 - Optional Kits; LED Light Kit; Ceiling Extension Kit

10
44
OPTION A
LED Light Kit
OPTION B
Ceiling Extension Kit
Line up the 2 pins on the LED light with the 2 Holes in the
Safety clip is engaged.
Re-check the correct assembly by gently pulling on the
LED LIGHT
”A“
150mm (6”)
“B”
26.6mm ROD
Suitable for Raked Ceiling up to 17
“B” Extension Rod Length
115mm Rod (4
17/32”
)
600mm Rod (23
5/8”
)
900mm Rod (35
7/16”
)
Accessories Required
Included
Not Included
Not Included
“A” Ceiling to Fan blade
420mm (16
17/32”
)
910mm (35
53/64”
)
1210mm (47
41/64”
)
