AerAtron FR3 - Attaching Fan Motor Housing; Assembling Fan Blades

8
STEP 7
Attaching the Fan Motor Housing
Align the 3 tabs with the 3 holes on the
Housing and move upwards. Push tabs
inwards slightly before sliding upwards
STEP 8
Assembling the Fan Blades
A B
Place the Hub Upper onto a clean working area.
with the 2 holes in the Hub Upper.
screws for each Blade.
be used.
CLICK!
!
avoid damaging the fan/surface
