Aercus Instruments™ - WeatherRanger® 13 | P a g e
Figure 8a Figure 8b
Hockey Stick Mount Tripod Mount
SOUTHERN HEMISPHERE USERS!!!
For stations located in the Southern Hemisphere you must follow the southern
hemisphere wind recalibration instructions in Appendix 1 not the instructions directly
below otherwise your wind direction readings will be incorrect.
Northern Hemisphere Locations Only
Reference Figure 9. Locate the four wind vane compass rose indicators of N, E, S, W (representing
North, East, South and West). Align the compass rose direction upon final installation with a
compass or GPS.
Figure 9
