Aercus Instruments™ - WeatherRanger® 14 | P a g e
Reference Figure 10. Make sure the sensor array is completely level upon final installation. Failure
to do so will result in inaccurate rain gauge readings.
Figure 10
3.3.5 Reset Button and Transmitter LED
In the event the sensor array is not transmitting, reset the sensor array. To do this, with an open ended
paperclip press and hold the RESET BUTTON for three seconds to completely discharge the voltage.
Take out the batteries and wait one minute, while covering the solar panel to drain the voltage.
Put the batteries back in and resynchronise with the console by powering the console down (by removing
the AC adaptor), waiting 10 seconds and then reinserting the AC adaptor with the sensor array about 3m
away (to eliminate any interference issues).
Figure 11
